UN Big Bag
Created with Pixso. 600kg white UN big bag FIBC , Industrial dangerous goods Jumbo Bags

600kg white UN big bag FIBC , Industrial dangerous goods Jumbo Bags

Brand Name: SINOPACK
Model Number: SI-150061
MOQ: 500pcs
Price: negotiation
Delivery Time: 25-35days
Detail Information
Place of Origin:
CHINA
Certification:
SGS/CPTC
Material:
100% Virgin PP
Product Name:
UN Certified Bag
Certificate:
SGS/CPTC
UV Treatment:
Standard ASTM G 154-00
Capacity:
600kg
Safety Ratio:
6:1
Printing:
With UN Printing
Color:
White
Packaging Details:
on pallet or in bales
Supply Ability:
200k per month
Highlight:

UN certified bulk bags

,

UN Bulk Bags

Product Description

600kg UN big bag / FIBC with certification for dangerous products



Description:



1. UN certified big bags are available in different shapes and sizes which can be customized.
2. This is a special line of bulk bags dedicated to the transportation of dangerous materials.

3. They are made in accordance with the United Nations Recommendations on the Transportation

    of Dangerous Materials, more commonly known as the for road (ADR), railway (RID) and marine

    transportation (IMDG - Code).

4. They are large and designed for packaging category II and III materials defined in chapter 9 of

    the Orange Book Typical product - poisons, corrosives.


5. Types offered:
    13H1: PP FIBC uncoated without liner
    13H2: PP FIBC coated without liner
    13H3: PP FIBC uncoated with liner C
    13H4: PP FIBC coated with liner
     PP FIBC single-layer UN FIBC, it has identical parameters as the double-layer FIBC
6. Safe working load (SWL) is up to 3300LBS, with a safety factor (SF) of 6: 1.

7. UN FIBC are produced with flat, outlet, or conical bottoms that simplify the emptying process,

    especially with materials that don't flow so freely.



Specifications:



Item

UN certified Big Bag

Shape

circular / tube bag

Capacity

600kg

Safety factor

6:1

Base size

35*35’’,

36*36’’

Height

As per request

Color

White,

Material

100% virgin polypropylene, 6OZ to 7OZ

Coated,

Uncoated,

Uncoated with PE liner

Top type

skirt top,

with filling spout: 14’’(D)*18’’,

Bottom type

flat bottom,

discharge spout: 14’’(D)*18’’ with star petal or iris spout,

Lifting loops

width: 3’’

10’’ high

cross corner loops
color: white/yellow

Liner

PE tubular liner, PE form-fitted liner

Perimeter belt

Width:  2’’, 3’’

UV stabilized

1% UV to 3%  treated

Document pouch

PE ziplock,

Envelope type

Label

As per request

Printing

Four colors at most in one side

Stitching

Plain stitching, chain stitching, overlock stitching

Packing

Packed on pallets,

20pallets/20'FCL,

44pallets/40'FCL

Lead time

25days for 1 x 20'FCL;

45days for 1 x 40'FCL
