Chemical materials FIBC certified UN big bag capacity up to 3000lbs

Place of Origin CHINA
Brand Name SINOPACK
Certification SGS/CPTC
Model Number SI-150064
Minimum Order Quantity 500pcs
Price negotiation
Packaging Details on pallet or in bales
Delivery Time 25-35days
Supply Ability 200k per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Certificate SGS/CPTC Capacity Up To 3000lbs
Safety Ratio 6:1 UV Treatment Standard ASTM G 154-00
Product Name Big Bag With UN Certified Material 100% Virgin PP
Printing With UN Printing Color White
High Light

UN certified bulk bags

,

UN FIBC

Leave a Message
Product Description

UN big bag with certification, FIBC for dangerous goods with capacity up to 3000lbs



Description:



1. UN certified big bags are available in different shapes and sizes which can be customized.
2. This is a special line of bulk bags dedicated to the transportation of dangerous materials.

3. They are made in accordance with the United Nations Recommendations on the Transportation

    of Dangerous Materials, more commonly known as the for road (ADR), railway (RID) and marine

    transportation (IMDG - Code).

4. They are large and designed for packaging category II and III materials defined in chapter 9 of

    the Orange Book Typical product - poisons, corrosives.


5. Types offered:
    13H1: PP FIBC uncoated without liner
    13H2: PP FIBC coated without liner
    13H3: PP FIBC uncoated with liner C
    13H4: PP FIBC coated with liner
     PP FIBC single-layer UN FIBC, it has identical parameters as the double-layer FIBC.
6. Safe working load (SWL) is up to 3300LBS, with a safety factor (SF) of 6: 1.

7. UN FIBC are produced with flat, outlet, or conical bottoms that simplify the emptying process,

    especially with materials that don't flow so freely.



Specifications:



Item

UN certified Big Bag

Shape

circular/ tube bag

Capacity

Up to 3000LBS

Safety factor

6:1

Base size

39*39’’,

41*41’’

Height

As per request

Color

White

Material

100% virgin polypropylene, 6OZ to 7OZ

Coated,

Uncoated,

Uncoated with PE liner

Top type

skirt top,

with filling spout: 14’’(D)*18’’,

Bottom type

flat bottom,

discharge spout: 14’’(D)*18’’ with star petal or iris spout,

Lifting loops

width: 3’’

10’’ high

sling design with the loops sewed to the bottom
color: white/yellow

Liner

PE tubular liner, PE form-fitted liner

Perimeter belt

Width: 1.2’’, 2’’, 3’’

UV stabilized

1% UV to 3%  treated

Document pouch

PE ziplock,

Envelope type

Label

As per request

Printing

Four colors at most in one side

Stitching

Plain stitching, chain stitching, overlock stitching

Packing

Packed on pallets,

20pallets/20'FCL,

44pallets/40'FCL

Lead time

25days for 1 x 20'FCL;

45days for 1 x 40'FCL
