2200lbs UN big bag for storage dangerous goods

Place of Origin CHINA
Brand Name SINOPACK
Certification SGS/CPTC
Model Number SI-150069S
Minimum Order Quantity 500pcs
Price negotiation
Packaging Details on pallet or in bales
Delivery Time 25-35days
Supply Ability 200k per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Uv Treatment Standard ASTM G 154-00 Color White
Print With Or No Safety Ratio 5:1
Product Name Big Bag With UN Certification Material 100% Virgin PP
Certificate SGS/CPTC Capacity 2200lbs
High Light

UN certified bulk bags

,

UN Bulk Bags

Leave a Message
Product Description

2200lbs UN big bag , certified FIBC for storage of dangerous goods



Description:



1. UN certified big bags are available in different shapes and sizes which can be customized.
2. This is a special line of bulk bags dedicated to the transportation of dangerous materials.

3. They are made in accordance with the United Nations Recommendations on the Transportation of

Dangerous Materials, more commonly known as the for road (ADR), railway (RID) and marine

transportation (IMDG - Code).

4. They are large and designed for packaging category II and III materials defined in chapter 9 of the

Orange Book Typical product - poisons, corrosives.


5. Types offered:
13H1: PP FIBC uncoated without liner
13H2: PP FIBC coated without liner
13H3: PP FIBC uncoated with liner C
13H4: PP FIBC coated with liner
     PP FIBC single-layer UN FIBC, it has identical parameters as the double-layer FIBC
6. Safe working load (SWL) is up to 3300LBS, with a safety factor (SF) of 6: 1.

7. UN FIBC are produced with flat, outlet, or conical bottoms that simplify the emptying process,

especially with materials that don't flow so freely.



Specifications:



Item

UN certified Big Bag

Shape

U-panel / Four-panel bag

Capacity

2200LBS

Safety factor

6:1

Base size

39*39’’,

41*41’’

Height

As per request

Color

White

Material

100% virgin polypropylene, 6OZ to 7OZ

Coated,

Uncoated,

Uncoated with PE liner

Top type

skirt top,

with filling spout: 14’’(D)*18’’,

Bottom type

flat bottom,

discharge spout: 14’’(D)*18’’ with star petal or iris spout

Lifting loops

width: 2’’ / 3’’

10’’ high

side-seam loops
color: white/yellow

Liner

PE tubular liner, PE form-fitted liner

Perimeter belt

Width: 1.2’’

UV stabilized

1% UV to 3%  treated

Document pouch

PE ziplock,

Envelope type

Label

As per request

Printing

Four colors at most in one side

Stitching

Plain stitching, chain stitching, overlock stitching

Packing

Packed on pallets,

20pallets/20'FCL,

44pallets/40'FCL

Lead time

25days for 1 x 20'FCL;

45days for 1 x 40'FCL
